Product Overview
The 1756-IR12 is an Allen-Bradley ControlLogix module providing twelve RTD (Resistance Temperature Detector) input channels. It integrates into a ControlLogix I/O chassis via the system backplane. The device converts RTD resistance into IEEE 32-bit floating-point temperature values using a sigma-delta converter. It is used in process monitoring, temperature logging, and industrial control systems requiring multiple temperature inputs in a single module.
Best Suited For
- ControlLogix chassis with multiple RTD inputs
- Industrial temperature measurement applications
- Continuous temperature monitoring in process systems
- Retrofit or expansion of existing ControlLogix analog I/O racks
Channels
12 RTD inputs
Data format
IEEE 32-bit floating point
Conversion method
Sigma-Delta
Scan time (min)
50 ms
Isolation (Inputs to backplane)
250 V reinforced
Technical Specifications
I/O & Electrical
Channels
12 RTD inputs
RTD excitation current
600 µA
Overvoltage protection, max
±30 V DC
Communication & Power
Data format
IEEE 32-bit floating point
Module conversion method
Sigma-Delta
Physical & Environmental
Power dissipation, max
Series B 2.75 W; Series A 2.7 W
Thermal dissipation
Series B 9.38 BTU/hr; Series A 9.2 BTU/hr
Module input scan time, min
50 ms
Certifications
China CCCCEAustralian RCMKorean KCATEXIECExUL ListedEurAsian EEC
Certified: China CCC, CE, Australian RCM, Korean KC, ATEX, IECEx, UL Listed, Eurasian Economic Community (as of 17 May 2026).
