The 1756-OB16I is an Allen-Bradley ControlLogix 16-point isolated sourcing DC output module. Designed for 10 … 30 V DC operation, it provides sixteen individually isolated outputs rated at 1 A per point. It mounts in a ControlLogix chassis and interfaces via the backplane. Typical uses include general discrete DC output control, on-machine actuation, or interfacing with field devices such as solenoids, indicators, and pilot devices in industrial automation systems. 1756-OB16I supports modular I/O architecture within ControlLogix systems.
Best Suited For
- Discrete DC output control in ControlLogix systems
- Machine-level actuation of solenoids, relays or valves
- Modular expansion of ControlLogix I/O capacity
- Isolated channel output applications
Channels
16 isolated outputs
Output rating
1 A per point (10 … 30 V DC)
Isolation voltage
250 V continuous
Backplane power
1.8 W
Power dissipation
3.6 W @ 60 °C
Technical Specifications
I/O & Electrical
Output voltage range
10 … 30 V DC
Output current per point
1 A
Number of output channels
16
Isolation (outputs-to-outputs)
250 V continuous
Communication & Power
Backplane current @ 5 V
350 mA
Backplane current @ 24 V
2.5 mA
Total backplane power
1.8 W
Power dissipation max
3.6 W @ 60 °C
Physical & Environmental
Slot width
1
Enclosure type
None (open-style)
RTB keying
User-defined mechanical
Temperature code
T4
Certifications
CEUL ListedcULusATEXIECEx
