The 2090-CSBM1DF-18AA03 is part of the Allen-Bradley 2090 Series Kinetix Single-DSL cable family. It provides combined motor power, feedback, and brake conductors in a single non-flex cable assembly. In a motion control system, it connects a Kinetix servo drive (e.g., Kinetix 5500) to a motor using a SpeedTec DIN connector at the motor end and flying leads at the drive end. Designed for single-motor installations, it is used widely in industrial automation for motion axes requiring power, encoder feedback, and brake, in a consolidated cable format. Part number may appear also as 2090-CSBM1DF-18AAxx where "xx" indicates length.

Best Suited For

Single-axis Kinetix 5500 drive installations
Applications requiring power, feedback, and brake conductors in one cable
Environments where a fixed, non-flex cable route is acceptable
Wiring schemes using SpeedTec DIN motor connectors

Wire gauge

18 AWG (1.0 mm²)

Cable type

Power / feedback / brake, standard non-flex

Motor connector

Single SpeedTec DIN

Drive-end connection

Flying-lead at 5500 drive end

Outer diameter

15 mm (~0.59 in.)

Technical Specifications

I/O & Electrical

Nominal voltage

1000 V

Conductor cross-section

0.82 mm²

Conductor surface

Tinned copper

Communication & Power

Cores

8 (4 power, 2 feedback, 2 brake)

Protective conductor

Yes

Core identification

By color

Physical & Environmental

Outer diameter

15 mm (0.59 in.)

Sheath color

Orange (RAL 2003)

Max. conductor temperature

105 °C

Static bend radius

7× cable diameter
