2090-SR040-18 Allen-Bradley
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 2090-SR040-18 is an external passive shunt resistor module in the Allen-Bradley Ultra3000 family. It supplements internal shunt capacity of Ultra3000 servo drives when elevated energy dissipation is required. With a resistance of 40 Ω and continuous power rating of 1800 W, it enables extended braking capability in motion control systems. This part is typically used in applications requiring high-energy braking or energy-absorbing loads and is applicable to part number 2090-SR040-18.
Best Suited For
- Ultra3000 servo drives with exceeded internal shunt capacity
- High-energy braking or regenerative energy absorption
- Industrial motion control systems requiring external shunt modules
- Applications needing continuous 1800 W dissipation
