1762-IQ16 Allen-Bradley

Name: 1762-IQ16 Allen-Bradley
Brand: Allen Bradley
SKU: 1762-IQ16
Price: 450.0 USD
Availability: InStock

$450.00 - $450.00

$450.00

$450.00 - $450.00

$450.00

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (4) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Allen Bradley distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The 1762-IQ16 is an Allen-Bradley MicroLogix 1200 series expansion module providing 16 discrete 24 V DC sink/source inputs. It mounts to the proprietary backplane of a MicroLogix 1200 controller, delivering isolated digital input capacity. It is suited to collect status signals from field devices (e.g. pushbuttons, proximity sensors) and relay them into the controller logic. It is typically deployed in industrial control panels, OEM machines, and process monitoring systems where modular I/O expansion is required. 1762-IQ16 may be used up to six modules per controller.

Best Suited For

MicroLogix 1200 I/O expansion
Collecting discrete 24 V DC input signals
Panel-mounted modular control systems
Applications requiring isolated, sink/source inputs

Inputs

16 sink/source channels

Operating voltage

10…30 V DC

Bus current draw

70 mA @ 5 V DC (0.35 W)

Heat dissipation

5.4 W @ 30 V DC

Operating temperature

-20…65 °C

Technical Specifications

I/O & Electrical

Number of inputs

16

Voltage category

24 V DC sink/source

Operating voltage range

10…30 V DC (10…26.4 V DC at elevated temperature)

Nominal impedance

3 kΩ

On-state voltage, min

10 V DC

On-state current, min/nom/max

2.0 mA min @10 V DC / 8.0 mA nom @24 V DC / 12.0 mA max @30 V DC

Off-state voltage, max

5 V DC

Off-state leakage current, max

1.5 mA

Signal delay (on/off)

8 ms

Isolated groups

Group 1: inputs 0-7; Group 2: inputs 8-15

Backplane isolation

1200 V AC for 1 s or 1697 V DC for 1 s; 75 V DC working voltage (IEC Class 2 reinforced insulation)

Communication & Power

Bus current draw, max

70 mA @ 5 V DC (0.35 W)

Heat dissipation, max

5.4 W @ 30 V DC (4.3 W @ 26.4 V DC)

Physical & Environmental

Dimensions (H×W×D)

90 mm × 40.4 mm × 87 mm

Weight

230 g

Operating temperature

-20…65 °C (-4…149 °F)

Storage temperature, min

-40 °C

Altitude

2000 m

Operating humidity

5…95 % non-condensing

EN emissions/immunity standards

ESD, RF, EFT/B, surge per IEC and EN standards

Enclosure rating

None (open-style)

Certifications

UL Listed Hazardousc-ULus

UL Listed for Class I, Division 2 hazardous locations (Groups A, B, C, D); meets relevant IEC immunity and emission standards.
