1762-L24AWAR Allen-Bradley
Original price
$1,317.80
-
Original price
$2,475.00
Original price
$1,317.80
$1,317.80
-
$2,475.00
Current price
$1,317.80
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1762-L24AWAR is an Allen-Bradley MicroLogix 1200 programmable controller intended for industrial logic and automation tasks. It integrates fourteen 120 V AC digital inputs and ten relay outputs, with two serial ports supporting DF1, DH-485, Modbus RTU, and ASCII. It operates from a 100-240 V AC supply at 47-63 Hz and includes approximately 6 KB of memory. Typical uses include small machine control, packaging line automation, and legacy system maintenance.
Best Suited For
- Small-machine logic control
- Packaging and conveyor applications
- 130 mm DIN-rail installation
- Replacement in discontinued MicroLogix 1200 systems
Digital inputs
14 × 120 V AC
Relay outputs
10 relay
Power supply
100-240 V AC @ 47-63 Hz
Memory
6 KB
Communication
2 × serial (DF1, DH-485, Modbus RTU, ASCII)
Technical Specifications
I/O & Electrical
Number of inputs
14 digital inputs (120 V AC)
Number of outputs
10 relay outputs
Input on-state voltage range
79…132 V AC
Input off-state voltage range
0…20 V AC
Input on-state current
12 mA nominal @120 V AC
Input off-state leakage current
≤ 2.5 mA
Communication & Power
Communication ports
2 × RS-232 serial (DF1, DH-485, Modbus RTU, ASCII)
Input voltage range
100…240 V AC (-15%, +10%) @ 47…63 Hz
Inrush current
25 A for 8 ms @ 120 V AC
Heat dissipation
15.2 W
Physical & Environmental
Dimensions (H × W × D)
90 mm × 110 mm × 87 mm
Weight (shipping)
0.9 kg (2.0 lbs)
