Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 2711-B6C1 is a legacy Allen-Bradley PanelView 600 Standard operator terminal featuring both keypad and touchscreen input. It provides a 6-inch color active-matrix TFT display with Remote I/O and RS-232 printer communication. Designed for integration into discrete and batch industrial control systems, it serves as a local human-machine interface for operator input, status display, and basic interaction. It is part of the PanelView Standard 600 family and is commonly deployed in manufacturing, packaging, and process monitoring applications.
Best Suited For
- Mounting on machine control panels for local operator interaction
- Environments requiring Remote I/O communication with legacy PLCs
- Applications needing RS-232 printing of alarms or event logs
- Systems utilizing both keypad and touchscreen input
Display
5.5-in color TFT, 320 × 234 pixels
Input methods
Keypad (10 function keys) and touchscreen
Communication
Remote I/O and RS-232 printer port
Memory
170 KB RAM, 240 KB non-volatile
Technical Specifications
I/O & Electrical
Input voltage, AC
85…264 V AC, 47…63 Hz
Power consumption, AC
60 VA max
Input voltage, DC
18…32 V DC (24 V DC nominal)
Power consumption, DC
34 W max (1.9 A at 24 V DC)
Communication & Power
Communication ports
Remote I/O, RS-232 (printer)
Application memory
170 KB runtime, 240 KB non-volatile
Physical & Environmental
Display area
115 × 86 mm (4.54 × 3.4 in)
Dimensions (H × W × D)
192 × 290 × 116 mm (7.55 × 11.40 × 4.57 in)
Weight, approx.
2.0 kg (4.4 lb)
