Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1734-IR2E is a POINT I/O module from Allen-Bradley (Rockwell Automation) providing two single-ended, non-isolated high-resolution RTD input channels. It functions within a POINT I/O distributed I/O system under Studio 5000 Logix Designer control, enabling temperature measurement via resistance temperature detectors. Common uses include temperature monitoring and control in machinery, process loops, and industrial systems where precise RTD readings integrate into a modular I/O architecture. 1734-IR2E assists in extending analog input capacity in OEM panels, conveyor systems, and process skids.
Best Suited For
- Precision temperature monitoring with high-resolution RTD sensing
- Integration into POINT I/O distributed I/O systems
- Retrofit or expansion of existing Logix control racks
- Applications using 100 Ω Pt, α=0.00385 Euro sensors
Channels
2
Input resolution
16 bits (2.4 mΩ/count, 0.006 °C/count at 25 °C, Pt 385)
Supported sensor type
100 Ω Pt, α=0.00385 Euro (-50…+325 °C)
Power supply
24 V DC
Operating temperature
-20…55 °C (-4…131 °F)
Technical Specifications
I/O & Electrical
Number of inputs
2 single-ended, non-isolated
Input signal range
78.12…234.38 Ω
Input resolution
16 bits (2.4 mΩ/count, 0.006 °C/count at 25 °C)
Communication & Power
Power supply
24 V DC
Physical & Environmental
Operating temperature
-20…55 °C (-4…131 °F)
