150-C16NBD Allen-Bradley
Product image is representative; revision or series may vary.
Contact us to request a specific version.

150-C16NBD Allen-Bradley

$479.97 - $825.00
$479.97
$479.97 - $825.00
$479.97
Surplus - Tested (With Warranty)
Need a Specific Revision?
$479.97
2 in stock
New / Open-Box Surplus
Need a Specific Revision?
$825.00
4 in stock
Ships today if ordered by 1 PM CST
Overnight shipping available
Qty Available: (2) ✓ Verified Stock every 24hrs
Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Allen Bradley distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA
Same-day by 1 PM CST
Tested & inspected
Every unit, before it ships
1-year warranty
Backed direct by us
30-day returns
Hassle-free RMA
Stock verified / 24 hrs
Real-time availability
Photos on request
Your exact unit, ~5 min
Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The 150-C16NBD is an Allen-Bradley SMC-3 series single-direction smart motor controller designed for motor starting and protection in three-phase, line-connected motor systems. It handles motor currents from 5.3 A to 16 A (380-460 V AC) and accepts control power of 100-240 V AC at 50/60 Hz. Installed inline with motors, it provides overload protection, selectable starting profiles, and soft-stop capability, commonly used in pump, fan, conveyor, and general industrial motor control applications. Part number 150-C16NBD is compliant with IEC, UL/CSA/NEMA standards.

Best Suited For

  • Three-phase motor control (5.3-16 A range)
  • Applications requiring adjustable start torque and kick-start (e.g. pumps, conveyors)
  • Environments needing integrated overload protection
  • Retrofit or replacement in existing SMC-3 installations
Motor current range
5.3-16 A (380-460 V AC)
Control power
100-240 V AC, 50/60 Hz
Selectable kick-start
0%, 0.5 s, 1 s, 1.5 s at 450 % FLA
Soft-stop capability
Off, 100 %, 200 %, or 300 % of start time
Integrated overload protection
Yes (Trip Class 10, 15, 20)

Technical Specifications

I/O & Electrical

Motor current range
5.3-16 A @ 380/400/415/460 V AC, 3-phase
Control supply voltage
100-240 V AC, 50/60 Hz
Overload trip classes
10, 15, 20 selectable
Kick-start setting
450 % FLA selectable (0, 0.5, 1.0, 1.5 s)
Soft-stop
Off, 100 %, 200 %, or 300 % of start time
Integrated bypass
True

Communication & Power

Line-connected motor power, max
7.5 kW @ 380-415 V AC, 50 Hz
Delta motor power, max
5-10 Hp @ 460 V AC, 60 Hz
Voltage type for actuating
AC/DC
dv/dt protection
1000 V/µs (power circuit)
Repetitive peak voltage
1400 V per UL/CSA/NEMA (power circuit)

Physical & Environmental

Steady-state heat dissipation
14 W
Operating temperature (open)
-5 °C to 50 °C (23 to 122 °F)
Storage/transport temperature
-25 °C
Humidity
5-95 % noncondensing
Shock rating (Opsal)
15 g
Vibration
1.0 g peak, 0.15 mm displacement
Altitude
2000 m
Protection rating
IP2X (open type)
Dimensions (W×D×H)
44.8 mm × 110 mm × 139.7 mm
Weight
0.86 kg

Certifications

EACCCCRCMUKCAMorocco DOC

Certified: Eurasian Economic Community, China CCC, Australian RCM, UKCA, Morocco DOC (as of May 27 2026)
