1762-OX6I Allen-Bradley

Name: 1762-OX6I Allen-Bradley
Brand: Allen Bradley
SKU: 1762-OX6I
Price: 599.96 USD
Availability: InStock

$599.96 - $824.97

$599.96

$599.96 - $824.97

$599.96

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (4) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Allen Bradley distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The 1762-OX6I is an Allen-Bradley MicroLogix 1200 series expansion module providing six isolated relay outputs. Its principal function is to interface discrete control logic from a MicroLogix 1200 PLC to external devices via relay contacts. It connects through the integrated I/O bus and is suited for industrial control tasks such as driving lamps, contactors, solenoids, or other ac/dc loads within machine, process, or infrastructure automation systems.

Best Suited For

MicroLogix 1200 systems requiring isolated relay outputs
Machine control with discrete load switching
Panel-mounted expansion where isolating outputs simplifies wiring
Applications needing individual output isolation (e.g., noisy loads)

Number of outputs

6

Output type

Relay (AC/DC Type C)

Operating voltage range

5…265 V AC, 5…125 V DC

Heat dissipation (max)

2.8 W

Weight

220 g

Technical Specifications

I/O & Electrical

Number of outputs

6

Output type

Relay, individually isolated

Operating voltage

5…265 V AC; 5…125 V DC

Continuous current per common (max)

7 A

Controlled load current per module (max)

6 A @ 240 V AC

Bus current draw (max)

110 mA @ 5 V DC (0.55 W)

Signal delay, ON (typical/max)

6 ms / 10 ms

Signal delay, OFF (typical/max)

12 ms / 20 ms

Heat dissipation (max)

2.8 W

Communication & Power

Bus current draw (max)

110 mA @ 5 V DC (0.55 W)

Physical & Environmental

Width

40.4 mm

Height

90 mm

Depth

87 mm

Weight

220 g

Operating temperature

-20 °C to 65 °C

Storage temperature

-40 °C

Shock - operating

30 G panel-mounted (3 pulses/axis)

Shock - relay ops

7 G

Vibration - operating

10…500 Hz, 5 G, 0.030 in peak-to-peak, 2 hr/axis

Vibration - relay ops

1.5 G

Altitude (operating)

2000 m

Operating humidity

5…95% non-condensing

Certifications

UL Listedc-UL-usClass I Division 2CERCMKCMoroccoUKCA

UL Listed Industrial Control Equipment (US & Canada); UL Listed for Class I, Division 2, Groups A,B,C,D hazardous locations; CE (EMC, LVD, RoHS), RCM (Australia), KC (Korea), Morocco ministerial approval, UKCA as applicable.
