1768-PA3/A Allen-Bradley
Original price
$799.96
-
Original price
$2,677.50
Original price
$799.96
$799.96
-
$2,677.50
Current price
$799.96
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1768-PA3/A is an Allen-Bradley CompactLogix L4x AC/DC input power supply module. It supplies 24 V DC aux power to CompactLogix L4x controllers and associated I/O modules. It supports 85-265 V AC or 108-132 V DC input and delivers up to 3.5 A at 24 V DC per the CompactLogix L4x architecture. Typically used in CompactLogix control systems for factory or machine-level installation requiring consistent auxiliary DC power. Part number 1768-PA3/A integrates with L4x platform controllers and is now discontinued, replaced by later models.
Best Suited For
- Auxiliary 24 V DC power for CompactLogix L4x controller racks
- Installation on DIN-rail in machine-level CompactLogix systems
- Retrofits or replacements in L4x AC/DC installations
- Powering multiple 1768 and 1769 I/O modules in a CompactLogix rack
Input supply types
85-265 V AC or 108-132 V DC
Auxiliary output
24 V DC at 3.5 A
Power dissipation
30 W max
Efficiency
75 % typical
Technical Specifications
I/O & Electrical
Input voltage range
85…265 V AC or 108…132 V DC
Input frequency range
47…63 Hz (AC)
Auxiliary output current
3.5 A at 24 V DC
Power dissipation
30 W max
Efficiency
75 % typical
Physical & Environmental
Operating temperature
0 °C to 60 °C
Storage temperature
-40 °C to +85 °C
Relative humidity
5-95 % non-condensing
Vibration (operating)
5 g at 10-500 Hz
Shock (operating)
30 g
Shock (non-operating)
50 g
Emissions
CISPR 11 Group 1 Class A
ESD immunity
6 kV contact, 8 kV air
Radiated RF immunity
10 V/m 30-2000 MHz; pulse 900/1890 MHz; 1 V/m 2000-2700 MHz
EFT/B immunity
±4 kV at 5 kHz on power ports
Surge immunity
±2 kV line-line (DM), ±4 kV line-earth (CM) on AC; ±1 kV line-line, ±2 kV line-earth on DC
Conducted RF immunity
10 V rms 150 kHz-80 MHz
Voltage variation
IEC 61000-4-11/-29 dips and interruptions per spec
Certifications
c-UL-usUL ListedClass I Division 2CERCM
