1770-KF2 Allen-Bradley
Original price
$450.00
-
Original price
$672.00
Original price
$450.00
$450.00
-
$672.00
Current price
$450.00
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1770-KF2 is an Allen-Bradley Data Highway/Data Highway Plus asynchronous interface module. It serves as a bridge between RS-232-C or RS-422-A asynchronous devices and a Data Highway or Peer Communication Link network in PLC-5 control systems. Typically used in control rooms or desktop environments, the module enables integration of operator terminals, PCs, or legacy devices into an Allen-Bradley network for diagnostics, programming, or data exchange. Part number 1770-KF2 provides serial-to-network communication capability.
Best Suited For
- Connecting RS-232-C devices to Data Highway network
- Peer Communication Link integration with PLC-5 systems
- Point-to-point or multi-drop diagnostics and programming
- Control-room standalone installation
Interface type
Data Highway/RS-232-C/RS-422-A
Power consumption
0.30 A @ 115/230 VAC
Comm. speed (DH/DH+)
57,600 bps
Comm. speed (async)
110 - 9,600 bps
Operating temp.
0 °C to 45 °C
Technical Specifications
I/O & Electrical
Power consumption
0.30 A @ 115/230 VAC
Communication & Power
Data Highway / Peer Comm. speed
57,600 bps
Asynchronous link speed
110 - 9,600 bps
Interface ports
15-pin male D-connector (Data Highway), 15-pin male D-connector (Peer Comm), 9-pin female D-connector (DH monitor), 25-pin male D-connector (RS-232-C/RS-422-A)
Physical & Environmental
Operating temperature
0 °C to 45 °C (32 °F to 113 °F)
Storage temperature
-40 °C to 85 °C (-40 °F to 185 °F)
Humidity (operating)
10 % to 80 % non-condensing
