1771-HSN Allen-Bradley
Original price
$450.00
-
Original price
$924.00
Original price
$450.00
$450.00
-
$924.00
Current price
$450.00
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1771-HSN is a servo controller module within the Allen-Bradley PLC-5 1771 family. It interfaces through a 1771 I/O chassis slot and requires a plug-in memory cartridge (1771-HM or HMA) to operate. The module provides ±10 V DC analog command outputs and captures high-speed differential pulse inputs up to 250 kHz, with a 2 ms per-axis update period. It is typically deployed in motion control applications requiring tight coordination of axis command and feedback signals.
Best Suited For
- Servo motor control within PLC-5 systems
- High-speed pulse capture (up to 250 kHz)
- Integration with 1771 memory cartridge modules (HM/HMA)
- Industrial motion control applications
Module type
Servo controller
Analog command outputs
±10 V DC
Max input frequency
250 kHz differential
Update period
2 ms/axis
Technical Specifications
I/O & Electrical
Analog command outputs
±10 V DC
Max differential input frequency
250 kHz
Communication & Power
Backplane current
1.7 A
Fuse voltage
120 V
Physical & Environmental
Slots required
1 slot (in 1771 chassis)
Operating temperature
0 °C to 60 °C (32 °F to 140 °F)
Relative humidity
5 % to 95 % (non-condensing)
Weight
2.00 lbs (0.91 kg)
Dimensions
3.5 × 6.5 × 2 in.
Certifications
UL ListedCSA Certified
UL listed; CSA certified.
