The Allen-Bradley 1771-QB is a linear positioning module in the PLC-5 family, designed to be installed in a single slot of a 1771 Universal I/O chassis. It provides two independent hydraulic or servo control axes with a 2 ms per-axis update rate, enabling closed-loop control via PID and feed-forward algorithms. The module interfaces directly with linear displacement transducers and servo valves to implement position, velocity, and hydraulic control tasks.

Best Suited For

Hydraulic cylinder position control with Temposonics or equivalent transducers
Dual-axis motion control in PLC-5 systems
PID control of servo or proportional hydraulic valves
Integration into 1771 Universal I/O racks for retrofit or legacy systems

Axes

2 independent axes

Update rate

2 ms per axis

Analog output resolution

12-bit

Backplane current (typ/ max)

1.1 A / 1.6 A at 5 V DC

Operating temperature

-25 °C to 60 °C

Technical Specifications

I/O & Electrical

Discrete inputs per axis

7 (auxiliary digital inputs)

Discrete outputs per axis

2 digital outputs (In-position, Loop-Fault)

Analog outputs

±10 V DC up to 10 mA; ±20 mA up to 600 Ω; ±50 mA up to 240 Ω; ±100 mA up to 240 Ω

Analog output resolution

12-bit

Discrete input current

8 mA at 12 V DC; 16 mA at 24 V DC

Discrete input thresholds

Logic 0: 0-4 V DC; Logic 1: 10-30 V DC

Communication & Power

Backplane current (typical)

1.1 A at 5 V DC

Backplane current (maximum)

1.6 A at 5 V DC

Physical & Environmental

Operating temperature

-25 °C to 60 °C (-13 °F to 140 °F)

Non-operating temperature

-40 °C to 85 °C (-40 °F to 185 °F)

Relative humidity

5 % to 95 %, non-condensing

Vibration (operating)

2 g at 10-500 Hz

Shock (operating/non-operating)

30 g

Certifications

Low Voltage Directive (73/23/EEC)EN 61131-2Class I Div 2

Meets Directive 73/23/EEC Low Voltage Directive and EN 61131-2 Programmable Controllers equipment requirements and testing. Suitable for Class I, Division 2, Group A,B,C,D or non-hazardous locations.
