1791R-8B8P Allen-Bradley
Original price
$0.00
-
Original price
$1,747.50
Original price
$1,747.50
$0.00
-
$1,747.50
Current price
$1,747.50
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1791R-8B8P is a CompactBlock Remote I/O base module in the Allen-Bradley CompactBlock I/O 1791R series. It provides eight sinking inputs and eight sourcing outputs, enabling localized digital I/O interfacing via Remote I/O link. Installed in distributed control systems, it allows placement close to field devices-minimizing wiring runs and easing maintenance. Typical applications include machine-level I/O distribution in OEM equipment, conveyor systems, and remote sensing/actuation where space is limited.
Best Suited For
- Distributed I/O near sensors and actuators
- Applications with space constraints
- Remote I/O networking via Remote I/O link
- Compact digital I/O base module for machine-level integration
Inputs / Outputs
8 sinking inputs / 8 sourcing outputs
Input voltage range
On-state ≥ 10 V DC, Off-state ≤ 5 V DC
Output current
≤ 0.5 A each
Isolation
500 V AC (power-supply to RIO, group-to-group, group-to-logic)
Status
Discontinued
Technical Specifications
I/O & Electrical
Input type
Sinking
Output type
Sourcing
Input off-state voltage
≤ 5 V DC
Input on-state voltage
≥ 10 V DC
Input on-state current
2 mA @ 10 V DC min.
Input off-state current
1.5 mA max.
Output on-state voltage range
10-30 V DC
Output on-state current
≤ 0.5 A each
Communication & Power
Power dissipation
9.2 Watts max.
Thermal dissipation
31.4 BTU/hr max.
Physical & Environmental
Mounting
Panel or DIN-rail, horizontal or vertical
Installation
Must be mounted in secondary enclosure
Certifications
Module now discontinued; no further certification details available from official sources.
