5069-OB16F Allen-Bradley
Original price
$559.80
-
Original price
$1,001.00
Original price
$559.80
$559.80
-
$1,001.00
Current price
$559.80
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 5069-OB16F is an Allen-Bradley Compact 5000 Fast 16-point sourcing DC output module (Bulletin 5069). It functions as a discrete high-speed output stage in CompactLogix systems, providing sixteen sourcing channels for 24 V DC control signals with fast switching capability. Typically, it is mounted in CompactLogix 5380/5480 chassis or used as distributed or local I/O on CompactLogix controllers. Its fast response suits pulse-driven valves, motion timing, and high-frequency switching applications. Part number 5069-OB16F.
Best Suited For
- Pulse-driven valve control
- High-speed digital switching
- Motion timing synchronization
- Distributed I/O in CompactLogix systems
Channels
16 sourcing outputs
Output current per channel
0.5 A resistive
Total module current
8 A resistive max
Switching delay
10 µs ±1 µs @ 0.5 A
Technical Specifications
I/O & Electrical
Number of outputs
16 sourcing channels
Output voltage range
10-32 V DC
On-state current per channel
0.5 A resistive
Module total current (resistive)
8 A resistive
Surge current per point
1 A for 10 ms, repeatable every 2 s
Minimum pulse width
20 µs @ 0.5 A
Switching delay (backplane to screw)
10 µs ±1 µs @ 0.5 A
On-state voltage drop (max)
< 0.2 V DC
Off-state voltage (max)
5 V DC with 1 mA load
On-state current per channel (min)
1 mA
Leakage current per point (max)
< 0.5 mA per point
Communication & Power
MOD power draw
75 mA @ 18-32 V DC
MOD power passthrough
9.55 A @ 18-32 V DC
LA-power per channel
0.5 A @ 10-32 V DC
LA-power per module
8 A @ 10-32 V DC
SA-power passthrough
9.95 A @ 10-32 V DC
Physical & Environmental
Operating temperature
0…60 °C (32…140 °F)
Max surrounding air temperature
60 °C (140 °F)
Enclosure type
None (open-style)
Wire size (RTB18-SCREW)
0.5-1.5 mm² (22-16 AWG) single conductor
Wire size (RTB18-SPRING)
0.5-1.5 mm² (22-16 AWG) single conductor
Strip length (RTB18-SCREW)
12 mm (0.47 in.)
Strip length (RTB18-SPRING)
10 mm (0.39 in.)
RTB screw torque
0.4 N·m (3.5 lb·in)
Certifications
China CCCIECExAustralian RCMKorean KCCEATEXUL ListedUL Listed HazardousAmerican Bureau of ShippingRegistro Italiano NavaleEurasian Economic Community
