805405-5R Allen-Bradley
Original price
$8,503.34
-
Original price
$14,579.84
Original price
$8,503.34
$8,503.34
-
$14,579.84
Current price
$8,503.34
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 805405-5R is an Allen-Bradley Field Power Module from the DPS single-phase family. Installed in distributed power systems, it converts incoming AC field power (230 VAC ±10 %) into DC field power, supplying machine or field devices. It supports up to 12 kW output at ambient 40 °C with rated current of 60 A, and is convection cooled in an enclosed chassis. Part number 805405-5R fits into systems requiring reliable DC field supply under industrial conditions.
Best Suited For
- Supplying DC field power in distributed automation networks
- Applications requiring up to 12 kW DC output at 230 VAC input
- Machine-level or remote module installations in DPS systems
- Environments with ambient temperatures up to 40 °C
AC input range
230 VAC ±10 %
Maximum DC output power
12 kW
Rated current (at 40 °C)
60 A
Operating temperature
0 to 40 °C
Storage temperature
-40 to 85 °C
Technical Specifications
I/O & Electrical
AC field input voltage
230 VAC ±10 %
AC line frequency
48 to 62 Hz
Source rating
2 kVA to 30 kVA
Maximum short-circuit current
10 kA
Internal field fuse rating
90 A, 700 V (60 A unit)
One-minute overload
150 % of max current (once per hour)
Rated current @ 40 °C
60 A
Maximum rated power
12 kW
Communication & Power
Cooling
Convection cooled
Physical & Environmental
Operating temperature
0 to 40 °C (32 to 104 °F)
Storage temperature
-40 to 85 °C (-40 to 185 °F)
Humidity
5 to 95 %, non-condensing
Altitude
Up to 1000 m; derate current 1 % per 91.4 m above
Enclosure
Enclosed chassis, convection cooling
Dimensions (H×W×D)
523 mm × 180 mm × 220 mm (20.6 in × 7.1 in × 8.7 in)
Certifications
UL 508C, CSA C22.2 No. 14 (component)
Certifications
UL-508CCSA C22.2 No. 14
