Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The A02B-0236-C205 is a GE Fanuc detector interface module designed to provide coordinated signal interface for up to four axes within automation and robotics control systems. It connects via RS-232 and supports industry-standard Modbus RTU communication, enabling integration with upstream controllers or CNC units. Typical uses include axis detection signal interfacing in robot controllers, CNC systems, and retrofit applications where four-axis coordination and reliable signal communication are required. A02B-0236-C205 facilitates modular connectivity of axis detectors in automated equipment.
Best Suited For
- Axis detector signal interfacing in multi-axis robot systems
- Integration with controller systems using RS-232/Modbus RTU
- Retrofit installations requiring compact detector interface
- Environments with up to four axes requiring digital detection
Supported axes
4
Communication
RS-232, 9600 bps
Power consumption
≤ 2 W
Operating temperature
-20 °C to +60 °C
Weight
0.75 lb (0.34 kg)
Technical Specifications
I/O & Electrical
Number of supported axes
4
Communication & Power
Connector type
RS-232
Data rate
9600 bps
Protocol compatibility
Modbus RTU
Power supply voltage
24 V DC
Power consumption
≤ 2 W
Physical & Environmental
Operating temperature range
-20 °C to +60 °C
Humidity range
5 % to 95 % non-condensing
Dimensions (W×D×H)
56 mm × 90 mm × 43 mm
Weight
0.75 lb (0.34 kg)
