Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1404-M605A-DNT is an Allen-Bradley Powermonitor 3000 display module incorporating RS-485 (DF-1) plus DeviceNet communication capabilities. It integrates into industrial power monitoring systems-typically with PLC-5E, SLC 5/05, or ControlLogix controllers-to provide both explicit messaging and I/O assembly data over DeviceNet alongside traditional RS-485 links. The module supports concurrent dual-port communication and is suited for applications requiring both local RS-485 and networked DeviceNet integration. Part number 1404-M605A-DNT.
Best Suited For
- Dual-port communication via RS-485 and DeviceNet
- Integration with PLC-5E or SLC 5/05 based monitoring systems
- Power monitoring networks using DeviceNet I/O assembly data
- Facilities requiring concurrent RS-485 explicit messaging
Communications
RS-485 (DF-1) + DeviceNet
DeviceNet features
Adapter class, 125-500 kbps, up to 64 nodes
Update rates
100 ms (I/O), 250 ms (explicit)
Operating temp.
0 °C to +55 °C
Technical Specifications
Communication & Power
Communications ports
RS-485 (DF-1) and DeviceNet
DeviceNet baud rates
125 kbps, 250 kbps, 500 kbps, AutoBaud
DeviceNet node capacity
Up to 64 nodes including master
Update rate (I/O)
100 ms minimum
Update rate (explicit messaging)
250 ms minimum
Physical & Environmental
Operating temperature
0 °C to +55 °C
Storage temperature
-40 °C to +85 °C
Humidity
5% to 95% noncondensing
Vibration (operational)
10-500 Hz at 2 G (±0.012 in.)
Shock
30 G, 11 ms, operational and non-operational
