6SE6400-3CC02-2CD3 Siemens

Name: 6SE6400-3CC02-2CD3 Siemens
Brand: Siemens
SKU: 6SE6400-3CC02-2CD3
Price: 400.0 USD
Availability: InStock

$375.00 - $400.00

$400.00

$375.00 - $400.00

$400.00

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (3) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The Siemens 6SE6400-3CC02-2CD3 is a line reactor designed for SINAMICS V20 and MICROMASTER drive systems. It functions to reduce harmonics, improve power factor, and protect the inverter from voltage transients on the supply side. Classified as a frame size C, it is suitable for 3-phase motor drive applications such as pumps, fans, conveyors, and general machine automation in industrial control systems. 6SE6400-3CC02-2CD3 integrates directly with the inverter supply path to enhance drive performance and longevity.

Best Suited For

Mitigation of supply-side harmonics in 3-phase inverter systems
Integration with SINAMICS V20 and MICROMASTER inverters (frame size C)
Industrial motor-driven applications (pumps, conveyors, fans)
Protection of inverter against voltage disturbances

Rated current

22.8 A

Line voltage

200 … 240 V AC, 3-phase

Inductance

Not specified in official data

Degree of protection

IP20

Weight

2.2 kg

Technical Specifications

I/O & Electrical

Rated current

22.8 A

Line voltage

200 … 240 V AC

Phases

3-phase

Communication & Power

Input side connection

Screw-type terminal

Output side connection

Pigtail, 2.5 mm² (14 AWG)

Conductor cross-section (input)

1.5 … 6 mm² (16 … 10 AWG)

PE connection

M5 stud

Physical & Environmental

Dimensions (W×H×D)

150 × 213 × 50 mm

Weight

2.2 kg

Degree of protection

IP20 / UL open type

Certifications

cURusIP20

cURus
