6GK7542-5DX00-0XE0 Siemens

Name: 6GK7542-5DX00-0XE0 Siemens
Brand: Siemens
SKU: 6GK7542-5DX00-0XE0
Price: 1372.25 USD
Availability: InStock

$1,372.25 - $1,445.85

$1,372.25

$1,372.25 - $1,445.85

$1,372.25

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (5) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The Siemens CM 1542-5 communications module (6GK7542-5DX00-0XE0) connects an S7-1500 controller to PROFIBUS DP networks, functioning as a DP-V1 master or slave while supporting S7, PG/OP communication, data record routing, time-of-day synchronization and diagnostics. It mounts on the S7-1500 backplane in a single-width compact format. Common in industrial machine-level and panel communication setups, it enables integration of PROFIBUS DP devices with newer SIMATIC systems. Part number 6GK7542-5DX00-0XE0 is provided for reference.

Best Suited For

Integrating S7-1500 into existing PROFIBUS DP installations
Machine-level communication in mixed-protocol environments
S7 and PG/OP communication over PROFIBUS DP
Time-of-day synchronized data routing in industrial networks

Interface

1× PROFIBUS (RS-485, 9-pin Sub-D)

Supply

15 V DC via backplane, 200 mA

Power loss

3 W

Operating temp

0 °C … +60 °C (horizontal rack)

Weight

~0.4 kg

Technical Specifications

I/O & Electrical

Interface count

1

Interface type

PROFIBUS DP (RS-485, 9-pin Sub-D socket)

Communication & Power

Supply voltage

15 V DC (via S7-1500 backplane)

Current consumption

200 mA (typical)

Power loss

3 W (typical)

Transmission speed

9.6 kbps … 12 Mbps

Physical & Environmental

Mounting

S7-1500 rack (single-width compact module), S7-1500 mounting bar

Dimensions (W × H × D)

35 × 147 × 129 mm

Weight

400 g

Protection class

IP20

Ambient temp (horizontal)

0 °C … +60 °C

Ambient temp (vertical)

0 °C … +40 °C

Storage / Transport temp

-40 °C … +70 °C

Relative humidity

≤ 95 % at 30 °C, no condensation

Overvoltage category

II (IEC/EN 60664-1)

Certifications

RoHSWEEEREACH

RoHS compliant; WEEE take-back obligation; REACH Art. 33 compliance; country of origin Germany.
