6ES5955-3LC42 Siemens

Name: 6ES5955-3LC42 Siemens
Brand: Siemens
SKU: 6ES5955-3LC42
Price: 2700.0 USD
Availability: InStock

$2,700.00 - $9,814.50

$2,700.00

$2,700.00 - $9,814.50

$2,700.00

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (5) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The Siemens 6ES5955-3LC42 is a power supply module from the SIMATIC S5 series, designed for central controllers (ZG S5-135U/155U) and expansion units (EG 183/185U). It accepts selectable 120 V AC or 230 V AC input voltage and delivers regulated DC outputs of 5 V at 18 A, 15 V at 0.5 A, and coarse-regulated 24 V at 1 A. The module includes safe electrical separation per EN 60950, and is recognized under UL 508 and cUL C22.2 standards. This part is discontinued as of October 1, 2022. Part number 6ES5955-3LC42 integrates power conditioning for legacy industrial automation systems.

Best Suited For

SIMATIC S5-135U or S5-155U central controllers
EG 183U or EG 185U expansion units
Replacement of obsolete SIMATIC S5 power supplies
Industrial automation systems requiring multiple DC rails from one module

Input voltage

120 V AC or 230 V AC (selectable)

5 V output

18 A

15 V output

0.5 A

24 V output

1 A (coarse-regulated)

Technical Specifications

I/O & Electrical

Input voltage range

120 V AC (93-132 V) or 230 V AC (187-264 V)

Input frequency

50/60 Hz (47-63 Hz)

Input current at rated load

2.5 A rms at 120 V; 1.5 A rms at 230 V

Peak inrush current

26 A for 2 s (repetition 100 s)

I²t inrush value

4 A²·s

Efficiency (with fans)

> 0.63

Efficiency (without fans)

0.70

Max heat dissipation (with fans)

80 W

Max heat dissipation (without fans)

53 W

Stored energy (power failure)

> 20 ms

External battery supply

4.5 V

Input fuse

Wickmann G 19343-T4 A/250 V, 500 A·s

Certifications

UL RecognizedcUL RecognizedVDE 0805 / EN 60950 safe isolation

UL-recognized per UL 508 (Report E 143289); cUL listed per Canadian Standard C 22.2 No. 142
