6ES7131-6BF00-0DA0 Siemens

Name: 6ES7131-6BF00-0DA0 Siemens
Brand: Siemens
Price: 436.65 USD
Availability: InStock

$0.00 - $436.65

$436.65

$0.00 - $436.65

$436.65

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (2) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The Siemens SIMATIC ET 200SP digital input module 6ES7131-6BF00-0DA0 is a high-speed 8-channel 24 V DC input interface designed for ET 200SP distributed I/O systems. It supports three operational modes-standard digital input, oversampling, and four independent counters-and integrates I&M data functionality and isochronous mode for fast cycle times. Configurable via TIA Portal from V13 SP1, this module is suitable for control architectures using PROFINET or PROFIBUS. Part number 6ES7131-6BF00-0DA0 adheres to Siemens' ET 200SP platform specifications.

Best Suited For

Fast digital signal acquisition in ET 200SP I/O racks
Counting applications requiring up to four independent counters
Systems requiring isochronous mode (125 µs) on PROFINET
Integration with TIA Portal (V13 SP1 and above)
Applications using I&M data tracking

Channels

8 digital inputs

Supply voltage

24 V DC (19.2 … 28.8 V DC)

Maximum current consumption

70 mA (without sensor supply)

Power loss

1.5 W (typical)

Operational modes

Digital input, Oversampling, 4× Counters

Technical Specifications

I/O & Electrical

Number of digital inputs

8

Rated input voltage

24 V DC

Permissible input voltage range

19.2 … 28.8 V DC

Input current typ.

6 mA (for signal "1")

Current consumption max.

70 mA (without sensor supply)

Output current max.

700 mA (encoder supply)

Reverse-polarity protection

Yes

Communication & Power

Isochronous mode

Yes (125 µs)

I&M data support

Yes (I&M0 to I&M3)

PROFINET suitability

Yes; GSDML V2.3

Engineering support

TIA Portal V13 SP1; STEP 7 from V5.5 SP3

Physical & Environmental

Width

15 mm

Height

73 mm

Depth

58 mm

Weight

28 g

Operating temp. range (horizontal)

-30 … 60 °C

Operating temp. range (vertical)

-30 … 50 °C

Isolation tested to

707 V DC

Certifications

ULCEATEXIECExFMABSBVDNVLRRINA

Module carries Siemens EcoTech Profile and major international approvals including UL, CE, ATEX, IECEx, FM, maritime class societies among others.
