Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The Siemens 6ES7141-6BH00-0AB0 is a SIMATIC ET 200eco PN distributed I/O module providing 16 digital inputs (24 V DC) and integrated encoder supply outputs. It belongs to the ET 200eco PN platform and serves as a field I/O component in PROFINET-based automation systems. The module is designed for use in decentralized, IP 67-rated installations, typically mounted on machinery or in non-cabinet environments. It interfaces directly with PROFINET controllers, offering reliable input acquisition and encoder power supply within industrial control networks.
Best Suited For
- Field-level digital input acquisition in PROFINET systems
- Machinery and on-machine I/O in IP 67 environments
- Applications requiring local encoder supply (8 outputs)
- Use as spare or replacement part in ET 200eco PN installations
Digital inputs
16 (24 V DC)
Encoder supply outputs
8 × 24 V, 100 mA each
Protection rating
IP 67
Input voltage range
-3 … +5 V (0), +11 … +30 V (1)
Power consumption
Typ. 100 mA; Power loss typ. 6.5 W
Technical Specifications
I/O & Electrical
Digital inputs
16, 24 V DC
Input voltage (signal "1")
+11 … +30 V
Input voltage (signal "0")
-3 … +5 V
Input current (signal "1"), typ.
7 mA
Input delay (0→1 / 1→0), typ.
3 ms / 3 ms
Encoder supply outputs
8 × 24 V, 100 mA each, short-circuit protected
Communication & Power
Supply voltage
24 V DC
Input current, typ.
100 mA
Current consumption from 1L+, max.
4 A
Power loss, typ.
6.5 W
Physical & Environmental
Degree of protection
IP 67
Dimensions (W × H × D)
60 × 175 mm
Mounting
On-machine field module
