Product image is representative; revision or series may vary.
Contact us to request a specific version.
Contact us to request a specific version.
6ES7516-2GN00-0AB0 Siemens
Original price
$0.00
-
Original price
$5,629.38
Original price
$5,629.38
$0.00
-
$5,629.38
Current price
$5,629.38
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 6ES7516-2GN00-0AB0 is a SIMATIC DP, CPU 1516PRO F-2 PN module from Siemens. It serves as a centrally mounted CPU for the ET 200pro distributed I/O system, providing program execution and data handling capabilities in machine-level automation. With integrated PROFINET IRT and RT interfaces (one with a 3-port switch), it enables real-time communication over PROFINET networks. It includes 1.5 Mbyte of program memory and 5 Mbyte of data memory. The unit is offered as a spare part and features IP65/67 protection suitable for harsh industrial environments.
Best Suited For
- ET 200pro distributed I/O applications
- Outdoor or wash-down installations requiring IP65/67 protection
- Replacement of failed CPU modules in existing SIMATIC DP systems
- Real-time control systems using PROFINET IRT/RT communication
Program memory
1.5 Mbyte
Data memory
5 Mbyte
PROFINET interfaces
IRT (3-port switch), RT
Ingress protection
IP65/67
Work memory slots
SIMATIC Memory Card required
Technical Specifications
I/O & Electrical
Supply voltage (DC, rated value)
24 V
Permissible range (DC)
20.4 V - 28.8 V
Reverse-polarity protection
Yes
Current consumption (typical)
0.31 A
Current consumption (max)
0.4 A
Inrush current, max
0.4 A
Mains/voltage-failure stored energy time
5 ms
Communication & Power
Infeed power to backplane bus
2.275 W
Power loss, typical
5.3 W
Physical & Environmental
Degree of protection
IP65/67
Net weight
0.680 kg
Packaging dimensions
14.10 × 16.40 × 7.80 cm
Certifications
RoHSWEEEREACH
