1756SC-IF8H Allen-Bradley
Original price
$982.33
-
Original price
$1,490.03
Original price
$982.33
$982.33
-
$1,490.03
Current price
$982.33
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 1756SC-IF8H is an Allen-Bradley ControlLogix series module providing eight differential analog input channels with HART communication support. It accepts both current (4-20 mA, 0-20 mA) and voltage (0-10 V) signals. It integrates into the 1756SC platform, connects via the standard ControlLogix backplane, and is used for applications requiring simultaneous analog measurement and HART-based device diagnostics or parameterization in process control or industrial instrumentation environments. Part number 1756SC-IF8H.
Best Suited For
- Process automation requiring HART-enabled analog input
- Integration in ControlLogix I/O racks
- Differential current or voltage signal acquisition
- Applications needing combined analog and HART diagnostics
Channels
8 differential analog inputs
Signal types
Current (4-20 mA, 0-20 mA) or Voltage (0-10 V)
HART support
Yes
Backplane power (5.1 V)
300 mA
Power dissipation (max)
3.21-4.01 W
Technical Specifications
I/O & Electrical
Input signal types
4-20 mA, 0-20 mA, 0-10 V
Channels
8 differential
Backplane current (5.1 V)
300 mA
Backplane current (24 V)
70 mA
Power dissipation (max)
3.21-4.01 W
Thermal dissipation
13.7 BTU per hour
Resolution
16-21 bit
Isolation
50 V continuous between inputs
Communication & Power
HART protocol
Supported
Physical & Environmental
Enclosure
Open-style
