Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The Siemens 6SL3210-1KE11-8AP1 is a SINAMICS G120C-2 compact frequency inverter with integrated PROFIBUS-DP interface and Safe Torque Off (STO). It accepts 3-phase 380-480 V AC, delivering up to 0.55 kW in low-overload and 0.37 kW in high-overload conditions. It is applied in motor control loops for pumps, conveyors, fans and general machine tools, where compact footprint, fieldbus integration via PROFIBUS-DP and safety compliance are required.
Best Suited For
- Machine tool spindle or auxiliary motor control
- Conveyor belt speed regulation with integrated safety interface
- Pump/fan variable-speed drives with PROFIBUS-DP network connectivity
- OEM equipment requiring STO safety function and compact drive
Rated power (LO)
0.55 kW (150 % 3 s)
Rated power (HO)
0.37 kW (200 % 3 s)
Input voltage
3 AC 380…480 V +10 %/-20 %
Interface
PROFIBUS-DP + STO safety
Technical Specifications
I/O & Electrical
Standard digital inputs
6
Fail-safe digital inputs
1
Digital outputs (relay)
1 (DC 30 V, 0.5 A)
Digital outputs (transistor)
1 (DC 30 V, 0.5 A)
Analog/digital inputs
1 differential (10-bit)
Analog outputs
1 non-isolated + motor temperature sensor input (PTC/KTY/Thermo-Click, ±5 °C)
Communication & Power
Communication interface
PROFIBUS-DP
Rated current (LO)
1.70 A
Rated current (HO)
1.30 A
Rated current (IN)
1.80 A
Max. output current
2.60 A
Pulse frequency
4 kHz
Output frequency V/f control
0…550 Hz
Output frequency vector control
0…240 Hz
Power factor λ
0.70…0.85
Offset factor cos φ
0.95
Efficiency η
0.97
Power loss
32.7 W
Physical & Environmental
Protection rating
IP20
Filter class (integrated)
Unfiltered
General protection
UL OPEN TYPE (per similar variant)
Frame size / dimensions
FSAA - approx. 173 × 73 × 155 mm (HxWxD)
Short-circuit current rating
100 kA (with suitable fusing)
Certifications
UL ListedcULusCE
Safety-related STO function per G120C-2 design; UL/cUL listing implied for NEMA/UL Type 1 kits; conformant modules as part of SINAMICS G120C-2 DP FSA series.
