3RV2011-1EA10 Siemens

Name: 3RV2011-1EA10 Siemens
Brand: Siemens
SKU: 3RV2011-1EA10
Price: 472.0 USD
Availability: InStock

$472.00 - $696.00

$472.00

$472.00 - $696.00

$472.00

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (2) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The 3RV2011-1EA10 by Siemens is a circuit breaker from the SIRIUS 3RV2 series, designed for motor protection in industrial control systems. It provides adjustable thermal overload protection (2.8-4 A) and magnetic short-circuit trip (52 A), safeguarding three-phase motor circuits. The device supports AC voltages up to 690 V and is suitable for installation on 35 mm DIN rails in motor control centers, control cabinets, or decentralized motor protection panels. Typical uses include protection of small motors, branch circuits, or as part of starter combinations. 3RV2011-1EA10 integrates both overload and short-circuit protection functions.

Best Suited For

Three-phase motor protection up to 690 V
DIN-rail mounting in control panels
Overload and short-circuit protection in starter combinations
Applications requiring adjustable thermal trip (2.8-4 A)

Overload range

2.8-4 A

Short-circuit trip

52 A

Voltage rating

20-690 V AC

Poles / Size

3 poles / S00

Power loss

7.25 W (total), 2.4 W per pole

Technical Specifications

I/O & Electrical

Overload adjustment range

2.8-4 A

Short-circuit trip rating

52 A

Poles (main circuit)

3

Communication & Power

Operating voltage (rated)

20-690 V AC

Operating frequency

50-60 Hz

Operating current (AC-3, at 400 V)

4 A

Motor power (AC-3)

0.8 kW @ 230 V; 1.5 kW @ 400 V; 2.2 kW @ 500 V; 3 kW @ 690 V

Physical & Environmental

Power loss

7.25 W total, 2.4 W per pole

Insulation voltage (pollution degree 3)

690 V

Surge voltage resistance

6 kV

Shock resistance (IEC 60068-2-27)

25 g / 11 ms

Mechanical life (main/aux contacts)

100 000 cycles

Electrical endurance

100 000 cycles

Ambient temperature (operation)

-20 … +60 °C

Storage/transport temperature

-50 … +80 °C

Relative humidity (operation)

10 … 95 %

Installation altitude max

2 000 m

Mounting method

Screw and snap-on onto 35 mm DIN rail

Dimensions (H × W × D)

97 × 45 × 97 mm

Weight

347 g

IP rating (front)

IP20

Certifications

ULCSACCCATEXIECExEACABSBVDNVLREU DoCUK DoC

UL, CSA, CCC, ATEX, IECEx, EAC, UK and EU declarations of conformity, maritime class approvals (ABS, BV, DNV, LR).
