Product Overview
The 1746-NI4 is a four-channel analog input module in the Allen-Bradley SLC 500 platform. It provides selectable voltage (-10 V to +10 V DC) or current (-20 mA to +20 mA) differential inputs for precise signal acquisition in industrial control systems. Installed in an SLC 500 chassis, it interfaces sensors or transducers to PLC logic. Typical applications include process monitoring, analog sensor signal collection, and control feedback loops where accurate analog measurement is required. Part number 1746-NI4 integrates into standard SLC 500 architectures.
Best Suited For
- SLC 500 chassis analog signal acquisition
- Differential voltage or current sensor inputs
- Process monitoring and feedback control
- Retrofit and replacement in older SLC 500 installations
Channels
4 inputs
Input ranges
-10 V DC to +10 V DC; -20 mA to +20 mA
Converter resolution
16-bit
Backplane current draw
25 mA @ 5 V; 85 mA @ 24 V
Isolation
500 V AC / 710 V DC (1 min)
Technical Specifications
I/O & Electrical
Number of channels
4 differential analog inputs
Input ranges
Voltage: -10 V DC to +10 V DC; Current: -20 mA to +20 mA
Voltage input impedance
1 MΩ
Current input impedance
≈ 250 Ω
Converter resolution
16 bit
Conversion method
Delta-Sigma
Step response time
60 ms
Bandwidth
10 Hz
Common-mode rejection @60 Hz
105 dB
Normal-mode rejection @60 Hz
55 dB
Communication & Power
Backplane current draw @ 5 V
25 mA
Backplane current draw @ 24 V
85 mA
Isolation voltage
500 V AC, 710 V DC (1 min)
Physical & Environmental
Platform
SLC 500 chassis module
