6AV6643-0CD01-1AX1 Siemens

Original price $375.00 - Original price $2,859.98
Original price
$375.00
$375.00 - $2,859.98
Current price $375.00
Surplus - Tested (With Warranty)
Need a Specific Revision?
$375.00
2 in stock
New / Open-Box Surplus
Need a Specific Revision?
$2,859.98
3 in stock
Ships today if ordered by 1 PM CST
Overnight shipping available
Qty Available: (2) ✓ Verified Stock every 24hrs
Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Siemens distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA
Same-day by 1 PM CST
Tested & inspected
Every unit, before it ships
1-year warranty
Backed direct by us
30-day returns
Hassle-free RMA
Stock verified / 24 hrs
Real-time availability
Photos on request
Your exact unit, ~5 min
Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The Siemens 6AV6643-0CD01-1AX1 is a SIMATIC MP 277 touch-operated HMI panel featuring a 10.4 in TFT color display and 6 MB retentive configuration memory. It is used for operator-level machine control and monitoring in industrial environments. With touch screen input and WinCC flexible 2005 configurability, this part integrates into control systems for process visualization, data entry, and parameter adjustment. The part number 6AV6643-0CD01-1AX1 is blocked for new delivery as of January 1, 2015, but is still available as a spare item.

Best Suited For

  • Operator control stations in legacy SIMATIC systems
  • Visualization panels in industrial automation zones with medium resolutions
  • Retrofitting obsolete MP 277 series panels
  • Touch-based data entry for manufacturing floor monitoring
Display size
10.4 in
Resolution
640 × 480 px
Configuration memory
6 MB
Touch input
Yes (analog resistive)
Supply voltage
24 V DC

Technical Specifications

I/O & Electrical

Supply voltage
24 V DC
Rated voltage supply
24 V DC

Physical & Environmental

Screen diagonal
10.4 in
Display type
TFT, color (65 536 colors)
Resolution (horizontal × vertical)
640 × 480 px
Touch operation
Analog, resistive
Configuration memory
6 Mbyte
Ambient operating temperature
0 °C to 50 °C
Weight
2.72 kg
