6SL3040-0JA02-0AA0 Siemens
Sold out
Original price
$0.00
-
Original price
$1,061.50
Original price
$1,061.50
$0.00
-
$1,061.50
Current price
$1,061.50
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The 6SL3040-0JA02-0AA0 is the Siemens SINAMICS S110 Control Unit CU305 with CAN interface, designed to serve as the control module within the SINAMICS S110 servo drive system. It manages digital inputs and outputs and interfaces with power modules and encoders via a CAN bus. CU305 units typically implement safety-integrated or standard control for single-axis servo setups. This module is used in motion control applications such as on-machine drives, robotics, or single-axis positioning where CAN interface is preferred. The part number may appear in maintenance or replacement workflows as 6SL3040-0JA02-0AA0.
Best Suited For
- Single-axis servo control via CAN bus
- Retrofitting CU305-based servo systems
- On-machine embedded control under SINAMICS S110 platform
- Maintenance of SINAMICS S110 servo drives
Control Unit type
CU305 with CAN interface
Digital I/O (configurable)
3 fail-safe DI or 6 DI
Power requirement
0.8 A (incl. 350 mA HTL encoder + 0.5 A PM340)
Hardware versions
A-E
Technical Specifications
I/O & Electrical
Digital inputs (configurable)
3 fail-safe DI (floating) or alternatively 6 DI (floating)
Parameterizable I/O
Inputs can be parameterized as DI or DO
Communication & Power
Interface
CAN bus
Supply current
0.8 A (includes 350 mA for HTL encoder + 0.5 A for PM340)
