Product image is representative; revision or series may vary.
Contact us to request a specific version.
Contact us to request a specific version.
CJ1W-OA201 Omron
Original price
$521.16
-
Original price
$800.00
Original price
$521.16
$521.16
-
$800.00
Current price
$521.16
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The CJ1W-OA201 is a triac output unit within OMRON's CJ1 basic I/O family for CJ/NJ series programmable controllers. It provides eight triac outputs on a removable terminal block, functioning as an interface between the PLC controller and AC loads. Typical industrial roles include controlling AC indicators, heaters, small motors, or lamps in machinery, assembly lines, and process control systems.
Best Suited For
- Switching AC loads (lamps, small motors, heaters)
- Integration with CJ/NJ PLC racks
- Compact machine control panels
- Industrial process control applications
Output points
8
Max switching capacity
0.6 A @ 250 VAC per point (2.4 A per unit)
Response time (ON)
1 ms max.
Internal current consumption
220 mA max.
Weight
150 g max.
Technical Specifications
I/O & Electrical
Output points
8
Max switching capacity
0.6 A 250 VAC (2.4 A/unit)
Max inrush current
15 A (10 ms pulse)
Min switching capacity
50 mA 75 VAC
Leakage current
1.5 mA (200 VAC) max.
Residual voltage
1.6 VAC max.
ON response time
1 ms max.
OFF response time
½ load frequency + 1 ms or less
Surge protection
C.R absorber + surge absorber
Fuse
5 A (1/common), non-replaceable by user
Internal current consumption
220 mA max.
Communication & Power
Connection
Removable terminal block
Physical & Environmental
Weight
150 g max.
Certifications
CE
This unit does not carry cULus (Class I Division 2) certification; for that certification, see CJ1W-OA201-1.
