CS1H-CPU65H Omron
Original price
$1,344.75
-
Original price
$8,005.50
Original price
$1,344.75
$1,344.75
-
$8,005.50
Current price
$1,344.75
Trusted By
Product Details
Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.
Product Overview
The CS1H-CPU65H is a CPU unit in Omron's CS1H rack-based programmable logic controller family. It provides central program execution and system control within a multi-rack CS1 architecture, typically serving machine and process control in industrial automation. It integrates with up to seven expansion racks and supports a system I/O capacity up to 5,120 local digital points. CS1H-CPU65H is suitable for mid-to-large size discrete and continuous systems, especially where structured text or ladder logic via IEC 61131-3 is required.
Best Suited For
- Multi-rack industrial control installations
- Medium-to-large I/O count systems (up to 5,120 points)
- Applications requiring structured text or ladder IEC 61131-3 programming
- Integration with various special I/O and communication modules
Local I/O capacity
up to 5,120 points
Expansion racks supported
up to 7
Program memory
60K steps (approx.)
Data memory
128K words
Technical Specifications
Communication & Power
Internal communications ports
Peripheral port and RS-232C port
