Product Overview

The R88D-KN08H-ML2-Z is an Omron G5-series AC servo drive with built-in MECHATROLINK-II communication. It controls a 750 W servomotor (R88M-K series) in machine-level motion applications. Situated within industrial control systems, it provides precise speed/position regulation via Mechatrolink-II and integrates typical functions such as drive power stage and control circuit. Suitable for tasks requiring mid-range servo power delivery and networked control, the R88D-KN08H-ML2-Z forms part of Omron's G5 platform.

Best Suited For

750 W servomotor control (R88M-K)
Mechatrolink-II networked motion systems
Machine tool axis drive
Industrial automation installation

Motor capacity

750 W

Continuous output current

4.1 A (rms)

Power supply capacity

1.3 kVA

Input voltage

200-240 VAC (single- or three-phase)

Heat dissipation

30 W / 35.5 W (main circuit)

Technical Specifications

I/O & Electrical

Continuous output current (rms)

4.1 A

Power supply capacity

1.3 kVA

Communication & Power

Power supply voltage (main circuit)

200 to 240 VAC (170-264 V), 50/60 Hz

Control circuit heat value

4 W

Physical & Environmental

Ambient operating temperature

0 to +55 °C, 85% max (no condensation)

Storage temperature

-20 to +65 °C, 85% max (no condensation)

Vibration resistance

10-60 Hz at ≤5.88 m/s²

Insulation resistance

≥0.5 MΩ (500 V DC)

Dielectric strength

Between power and FG: 1,500 VAC, 1 min

Certifications

EN55011EN61000-6-2IEC61800-3EN61800-5-1EN954-1 Cat.3EN ISO 13849-1 PL c,dEN61508 SIL2EN62061 SIL2STO (EN61800-5-2)UL508CCSA C22.2 No.14KC

Compliance with EN55011, EN61000-6-2, IEC61800-3 (EMC); EN61800-5-1 (Low Voltage); Machinery standards: EN954-1 Cat.3, EN ISO 13849-1 PL c,d, EN61508 SIL2, EN62061 SIL2, EN61800-5-2 STO, IEC61326-3-1 SIL2; UL508C; CSA C22.2 No.14; KC certification.
