S8VK-G24024 Omron

Name: S8VK-G24024 Omron
Brand: Omron
SKU: S8VK-G24024
Price: 450.0 USD
Availability: InStock

$439.80 - $450.00

$450.00

$439.80 - $450.00

$450.00

Ships today if ordered by 1 PM CST

Overnight shipping available

Qty Available: (2) ✓ Verified Stock every 24hrs

Questions? (833) 800-7748

All products listed are sold by PLC Department, an independent supplier — not an authorized Omron distributor. Covered by our 1-year warranty. By purchasing you acknowledge our full disclaimer. Read & agree ↓

Ships from Texas, USA

Same-day by 1 PM CST

Tested & inspected

Every unit, before it ships

1-year warranty

Backed direct by us

30-day returns

Hassle-free RMA

Stock verified / 24 hrs

Real-time availability

Photos on request

Your exact unit, ~5 min

Trusted By

Product Details

Description · Specifications · Product Overview

Specifications provided for reference. Verify critical details against official manufacturer documentation before installation.

Product Overview

The S8VK-G24024 is a member of Omron's S8VK-G series of single-phase switch-mode DIN-rail power supplies. It delivers regulated 24 V DC output at up to 10 A (240 W nominal), with a 120 % boost current capacity (12 A) for short-term peak loads. The supply accepts 100-240 VAC or 90-350 VDC input, includes automatic overload and overvoltage protection, and is rated for operation from -40 °C to +70 °C. This module is suitable for application in industrial control panels, machine feeding, and auxiliary power systems.

Best Suited For

Control panel DIN-rail 24 V bus feeding
Backup or redundant auxiliary power (via boost capability)
Single-phase AC or DC input systems
Harsh environment cabinets (wide temperature range)
Compact footprint machine retrofits

Output voltage

24 V DC

Rated output current

10 A

Boost-current capacity

12 A

Input voltage range

100-240 VAC / 90-350 V DC

Operating temperature

-40 °C to +70 °C

Technical Specifications

I/O & Electrical

Input voltage

100-240 VAC; 90-350 V DC

Output voltage

24 V DC

Rated output current

10 A

Boost current

12 A

Overload protection

Yes, automatic reset

Overvoltage protection

Yes, shuts off input

Communication & Power

Ripple & Noise (100-240 VAC, full load)

180 mVp-p max. at 20 MHz bandwidth

Efficiency (230 VAC)

92 % typ.

Inrush current (cold start, 25 °C)

16 A typ. (115 VAC), 32 A typ. (230 VAC)

Power factor (230 VAC, 100 % load)

≥ 0.9

Physical & Environmental

Operating temp.

-40 °C to +70 °C (derating required)

Storage temp.

-40 °C to +85 °C

Humidity

0 % to 95 % (non-condensing)

Vibration

10-55 Hz, 0.375 mm half amplitude, 2 h each in X/Y/Z

Shock

150 m/s², 3× each ±X/±Y/±Z

Degree of protection

IP20

Weight

Approx. 620 g

Mounting

DIN-rail (side-by-side up to 55 °C)

Certifications

UL ListedcULCERCMLloyd's RegisterSEMI F47-0706

UL Listed (UL 508, Class 2 output under UL 1310), UL 62368-1 recognition; cUL (CSA C22.2 No 107.1, Class 2 under CSA C22.2 No 223), cUR (CSA C22.2 No 62368-1); EN 62477-1, EN 62368-1; PELV compliance (EN 60204-1, EN 62477-1); EN 61558-2-16; CE marking; RCM; Lloyd's Register; SEMI F47-0706 for 200-240 VAC.
